Rebar Detailing
Cast-in-place concrete
Footings, walls, slabs, columns, beams and stairs detailed for placement and fabrication.
DeliverablePlacing + BBS
Fabrication-ready detailing
Structural Detailing & Shop Drawing Services
Rebar and steel shop drawings your fabricator can cut from and your crew can place from, with schedules, connection details and erection drawings coordinated to the contract documents.
- Rebar & steelPlacing and erection drawings
- Bar schedulesBending and cut lists
- Submittal-readyFormatted for EOR review
Service overview
Shop Drawings Ready for the Fabrication Floor
We prepare reinforcing steel and structural steel shop drawings that fabricators can cut from and crews can install from: placing and erection drawings, assembly and piece drawings, bar bending schedules and connection details, all coordinated with the contract documents.
Every set is checked by a senior detailer before it goes out for approval, and engineer-of-record comments are turned around quickly so fabrication and deliveries stay on schedule.
What you receive
- Rebar placing and steel erection drawings
- Assembly and piece drawings
- Bar bending schedules and bills of materials
- NC/DXF files for fabrication on request
- Approval and revision tracking
Who it's for
- Rebar fabricators
- Steel fabricators
- Erectors & installers
- General contractors
Software we use
- Tekla Structures
- AutoCAD
- Autodesk Revit
- RebarCAD
- Bluebeam Revu
What's included
What's Included in Our Detailing Services
Drawings and schedules prepared to the project specifications and standard detailing practice.
Rebar placing drawings
Plans, elevations and sections showing bar marks, sizes, spacing, laps and placement for every element.
Placing drawingsBar marksBar bending schedules
Cut lengths, bend shapes and quantities by bar mark, organized for fabrication and delivery.
Bending schedulesBy releaseSteel shop drawings
Fabrication drawings for beams, columns, braces and miscellaneous steel, with piece marks and dimensions.
Shop drawingsPiece marksConnection details
Bolted and welded connections drawn clearly for fabrication and engineer review.
ConnectionsWeld & boltErection drawings
Anchor bolt plans, framing plans and erection sequences for the field crew.
Erection setAnchor boltsMaterial lists & weights
Bills of materials with weights by member or bar mark, for ordering and progress billing.
Bill of materialsWeights by mark
Detailing scopes
Detailing for Every Structural Package
From foundations to the roof, and from rebar to miscellaneous metals.
Scope 01 Scope 02 · Most requested Structural Steel
Framing & connections
Beams, columns, bracing and connections detailed for fabrication and erection.
DeliverableShop + erectionScope 03 Miscellaneous Metals
Stairs, rails & embeds
Stairs, railings, lintels, embeds and support steel detailed to fit the architectural drawings.
DeliverableShop drawingsScope 04 Precast & Tilt-Up
Panel detailing
Panel layouts, reinforcement, embeds and lifting inserts for precast and tilt-up elements.
DeliverablePanel drawings
How we work
Our 5-Step Detailing Process
Coordinated with your engineer of record and fabricator from start to finish.
- 1
Contract documents
Send structural and architectural drawings, specifications and any answered RFIs.
- 2
Model & coordinate
We build the detailing model and raise conflicts or missing information as RFIs.
- 3
Detail & schedule
Placing drawings, shop drawings and schedules are produced with consistent marks and callouts.
- 4
Independent check
A separate detailer checks every sheet against the contract documents before submittal.
- 5
Submittal & release
Drawings go out for approval; we incorporate comments and issue fabrication releases.
Footing F-2: 4 #6 E.W.
Mark 6F2 · 8'-6"
Wall W-1: #5 @ 12" O.C.
Mark 5W1 · 10'-0"
Grade beam GB-3
#4 stirrups @ 8" O.C.
Layered vector PDFLinked Excel quantities
Sample deliverable
Bar Schedules Ready for the Shop
Every release comes with a bar list your fabricator can load directly, with weights for ordering and billing.
Live formulas, unlocked cellsWeights calculated from standard bar weights
| Mark | Size | Qty | Length | Shape | Weight (lb) |
|---|---|---|---|---|---|
| Footings | |||||
| 6F2 | #6 | 96 | 8'-6" | Straight | 1,226 |
| 5F4 | #5 | 64 | 5'-0" | Straight | 334 |
| Walls & grade beams | |||||
| 5W1 | #5 | 210 | 10'-0" | Straight | 2,190 |
| 4GB3 | #4 | 180 | 6'-8" | Stirrup (T1) | 802 |
| 5D1 | #5 | 48 | 3'-0" | 90° hook (T2) | 150 |
Release 1 total weight4,702 lb
- Marked-up PDF drawings included
- Unlocked Excel (.xlsx)
- Rush turnaround available
Project types
Project Sectors We Estimate
Experience across commercial, residential, institutional and public work in all 50 states.
Residential
Custom homes, additions, remodels and production housing, from single plans to whole subdivisions.
Custom to production
Commercial Office
Core-and-shell buildings, tenant fit-outs, renovations and corporate interiors.
Shell & interiors
Retail & Hospitality
Restaurants, retail centers, hotels and multi-site rollouts that need consistent pricing.
Single site or rollout
Multi-Family
Garden-style, podium and mid-rise apartments, senior living and student housing.
Wood, podium & mid-rise
Industrial & Warehouse
Distribution centers, manufacturing plants, cold storage and flex buildings.
Tilt-up & pre-engineered
Healthcare
Medical offices, clinics, surgical centers and hospital renovations with specialty systems.
Specialty MEP
Education
K-12 schools, university buildings, labs and athletic facilities, including phased work.
Prevailing wage ready
Public Works & Civil
Municipal buildings, fire and police stations, parks and site infrastructure.
Public bid formats
Why Bidnora
Shop Drawings That Get Approved
Every review cycle costs schedule. Our detailers aim to get it right on the first submittal.
Fewer review cycles: Drawings are checked against the contract documents before they reach the engineer.
RFIs raised early: Conflicts and missing details come up before fabrication, not after.
Field-friendly sheets: Layouts are arranged so crews find what they need quickly on site.
Fabrication-ready data: Schedules and material lists export cleanly for your shop's software.
“The color-coded markups make checking quantities quick. We bid more drywall and framing work last quarter than ever, without adding an estimator.”
Trade takeoffs
Explore Specialized Trade Estimating
Need single-scope detail? We prepare trade takeoffs organized the way specialty subcontractors price their work.
- ConcreteExplore trade
- MasonryExplore trade
- MetalExplore trade
- DrywallExplore trade
- InsulationExplore trade
- PaintingExplore trade
- FlooringExplore trade
- ElectricalExplore trade
- PlumbingExplore trade
- All tradesView the list
Other services:
Common questions
Structural Detailing & Shop Drawings FAQs
We follow the project specifications and standard industry practice for concrete reinforcing and structural steel detailing. If your project or fabricator has specific requirements, we'll match them.
Ready for bid day
Need Shop Drawings for Your Next Package?
Send the structural drawings and your schedule, and we'll reply with a fixed quote and release plan.
- 100% confidential
- NDA on request
- Fixed price before we start
